Keeping this in view, why does my pilot light go out when I release the pilot light knob?
The most likely of those is that the thermocouple needs to be replaced. The button you press to light the pilot bypasses the thermocouple. When you release the button, the thermocouple ensures that unburned gas doesn't get released by shutting off the gas when it's not heated by the burning pilot light.
Similarly, should the pilot light always be on in a gas furnace? If you have an older gas furnace, your heating unit relies on a little blue flame known as a pilot light to ensure ignition of the burners. Water heaters, gas fireplaces and old gas stoves also often have similar pilot lights. Since the pilot light needs to remain active, your furnace is always consuming some gas.
People also ask, what would cause a pilot light to keep going out?
Usually, a problem with the thermocouple causes the pilot light to go out. The thermocouple is the small copper rod that the pilot light hits. The thermocouple's job is to shut a gas safety valve if the pilot light goes out. That's important because gas is always being supplied to the pilot to keep the flame lit.
How do you know if you have a bad thermocouple?
If you can't get the flame to light at all, and you're sure the gas is on, there's probably an obstruction in the pilot tube. If the flame lights and goes out when you release the gas control knob after holding it in for the recommended 20 to 30 seconds, that's the sign of a thermocouple malfunction.
Related Question AnswersWhat does a thermocouple look like?
The thermocouple looks like a piece of metal tubing smaller than a soda straw. To find it, first locate the gas control box. This is the box that the main gas line enters, where you turn the gas on in the furnace. The other end of the thermocouple sits in the flame of the pilot light.How long does a thermocouple last?
Thermocouples can last several years, but they don't typically last as long as the furnace itself. If the pilot remains lit, but the main furnace doesn't stay lit, it's time to replace the thermocouple.Can you clean a thermocouple?
If the Thermocouple is faulty it will cause the unit to shut down. How to clean? Remove Thermocouple from pilot assembly, using steel wool or emery cloth to lightly clean the tip removing any soot or build up that might have accorded due to an improper pilot flame.How much does it cost to replace a thermocouple?
Thermocouple Replacement - $20-$150 Calling a professional plumber to install a new thermocouple should only be up to $150. If you do the work yourself, you will only pay the price of the part which is about $20.How do you test a thermocouple?
Steps- Locate the pilot light controls on the gas valve.
- Turn the pilot light on for 30 seconds.
- Release the button to see if the pilot light goes out.
- Turn off the gas supply to test the thermocouple again.
- Count to 20 and wait for the pilot light to go out.
- Listen for clicking near the gas valve.
How do I make my pilot light stay lit?
How to Maintain a Furnace- Step 1: Find pilot light assembly. It typically has a gas valve with ON, OFF and PILOT settings.
- Step 2: Turn the valve to the OFF position and wait three minutes.
- Step 3: Switch valve to PILOT setting.
- Step 4: If the pilot flame won't stay lit, the opening may be clogged.
How do you adjust the pilot light on a gas furnace?
How to Adjust the Pilot Light Flame on a Gas Furnace- Locate the access plate on the front of your furnace, and unscrew the screws that are connecting the access plate to your furnace.
- Observe the flame.
- Turn that screw counter-clockwise, and the flame should grow.
- Rotate the screw on the pilot light clockwise, and the size of the flame will decrease.
What causes a thermocouple to fail?
Changes in temperature can cause regular expansion and contraction in metal, which will cause thermocouples to weaken over time. After enough time, metal fatigue can cause a thermocouple to break. If thermocouples start to give out unusual readings, it may be suffering from metal fatigue.Is it dangerous if the pilot light goes out?
Can a Pilot Light Outage Be Dangerous? The worry here is that when a pilot goes out, the gas valve that supplies the fuel for the pilot flame could still be pumping gas. This can mean a buildup of gas, and when the pilot is relit or relights itself it could result in a very serious explosion.Can a thermocouple work intermittently?
a safety device that has started to go bad, or has failed permanently. In this client's case, the thermocouple was initially working intermittently, and then finally failed. This allowed the gas to flow long enough to heat up the thermocouple and generate some electrical current flowing back to the gas valve.What do you do when your pilot light goes out?
What Should You Do If Your Pilot Light Goes Out?- Locate the pilot light assembly, including the gas valve with “On,” “Off,” and “Pilot” settings, and pilot reset button.
- Rotate the valve to the “Off” position, and wait several minutes.
Does pilot light go out when power goes out?
Gas appliances tend to use a thermocouple (which is a self-powering device) to keep the gas valve to the pilot light open. This means that the light will not go out when you turn off the breaker.How do you test a thermocouple on a water heater?
If the pilot light doesn't stay lit, check the gas water heater thermocouple by keeping the pilot button depressed. Measure the current by using the multimeter device, set on millivolts. One probe of the meter should be connected to the copper sheath of the thermocouple and the other to the gas valve.How do you clean a pilot tube?
You can clear the pilot orifice with a piece of wire or a wire brush, and it isn't difficult to access.- Remove the cover plate at the bottom of the water heater.
- Turn the gas control to the "Off" position.
- Locate the pilot tube.
- Clean the pilot hole by brushing it with a stiff wire brush.
